2025 Equus Trailers 2 HAL

Angled load floats.

• Internal Height 7’4”
• Internal width net 6’4”
• Tailgate height 4’7”
• Standard GVM 3000 kg.
• Stall length and width built to clients’ request.
• Chassis galvanised. Rails 50 x 50 x 3 mm
• Drawbar 100 x 50 x 3 mm extending to front spring hanger on all floats.
• Sheeting, external uses .75 mm zincanneal in continuous lengths, rivet less and glued with polyurethane.
• Flooring is Hardwood Australian Form Ply, made specifically for the construction industry, mainly used in concreting form work, and is waterproofed on both sides and has a higher strength rating than the traditional double floor. It is screwed to floor joists at approximately 180 mm intervals. Floor joists are placed apart at 190 mm. intervals resulting in an exceptionally safe and stable floor.
• Natural rubber, anti slip,10 mm, dimpled, in continuous lengths to stall area. Also fitted to the tailgate with the edges completely sealed with polyurethane.
• Smooth natural rubber in continuous lengths to both stall walls to a height of 900.
• Internal stall walls are fully clad with galvanised sheeting, which is welded to the frame.
• Fittings/latches on dividers/head dividers and sliding dividers are designed with horse safety and comfort in mind. There are no sharp protrusions or edges. Latches close snuggly, eliminating most internal rattling. There are no protrusions on the rump wall. Latches are easily opened even with a horse leaning on a divider.
• Head dividers are filled in with 50 x 50 mm mesh which if fully welded.
• A Frame is filled in with aluminium chequer plate.
• Full sized steps to each side and steps on each side at the rear of guards are aluminium chequer plate clad. Guards are clad in aluminium chequer plate. The front is clad in aluminium chequer plate to a height of 760 mm.
